Skill Configuration

Summary: Configure skills with parameters, environment variables, and SWAIG field overrides. Understand the parameter schema and discovery options.

Configuration Methods

Method	Description
Parameters dict	Pass config when calling add_skill()
Environment variables	Set via OS environment
SWAIG fields	Customize tool metadata
External directories	Register custom skill paths

Parameter Dictionary

Pass configuration when adding a skill:

self.add_skill("web_search", {
    "api_key": "your-api-key",
    "search_engine_id": "your-engine-id",
    "num_results": 5,
    "min_quality_score": 0.4
})

Parameter Schema

Skills define their parameters via get_parameter_schema():

{
    "api_key": {
        "type": "string",
        "description": "Google API key",
        "required": True,
        "hidden": True,
        "env_var": "GOOGLE_API_KEY"
    },
    "num_results": {
        "type": "integer",
        "description": "Number of results",
        "default": 3,
        "min": 1,
        "max": 10
    },
    "style": {
        "type": "string",
        "description": "Output style",
        "enum": ["brief", "detailed"],
        "default": "brief"
    }
}

Parameter Properties

Property	Type	Description
type	string	Data type: string, integer, number, boolean, object, array
description	string	Human-readable description
default	any	Default value if not provided
required	bool	Whether parameter is required
hidden	bool	Hide in UIs (for secrets)
env_var	string	Environment variable source
enum	array	Allowed values
min/max	number	Value range for numbers

Environment Variables

Skills can read from environment variables:

import os

## Set environment variable
os.environ["GOOGLE_API_KEY"] = "your-key"

## Skill reads from params or falls back to env
self.add_skill("web_search", {
    "api_key": os.getenv("GOOGLE_API_KEY"),
    "search_engine_id": os.getenv("SEARCH_ENGINE_ID")
})

SWAIG Fields

Override SWAIG function metadata for skill tools:

self.add_skill("datetime", {
    "swaig_fields": {
        # Add filler phrases while function executes
        "fillers": {
            "en-US": [
                "Let me check the time...",
                "One moment..."
            ]
        },
        # Disable security for testing
        "secure": False
    }
})

Available SWAIG fields:

Field	Description
fillers	Language-specific filler phrases
secure	Enable/disable token validation
webhook_url	Override webhook URL

External Skill Directories

Register custom skill directories:

from signalwire_agents.skills.registry import skill_registry

## Add directory at runtime
skill_registry.add_skill_directory("/opt/custom_skills")

## Environment variable (colon-separated paths)
## SIGNALWIRE_SKILL_PATHS=/path1:/path2:/path3

Entry Points

Install skills via pip packages:

## In setup.py
setup(
    name="my-skills-package",
    entry_points={
        "signalwire_agents.skills": [
            "weather = my_package.skills:WeatherSkill",
            "stock = my_package.skills:StockSkill"
        ]
    }
)

Listing Available Skills

from signalwire_agents.skills.registry import skill_registry

## List all available skills
skills = skill_registry.list_skills()
for skill in skills:
    print(f"{skill['name']}: {skill['description']}")

## Get complete schema for all skills
schema = skill_registry.get_all_skills_schema()
print(schema)

Multi-Instance Configuration

Skills supporting multiple instances need unique tool names:

## Instance 1: News search
self.add_skill("web_search", {
    "tool_name": "search_news",      # Unique function name
    "api_key": "KEY",
    "search_engine_id": "NEWS_ENGINE"
})

## Instance 2: Documentation search
self.add_skill("web_search", {
    "tool_name": "search_docs",      # Different function name
    "api_key": "KEY",
    "search_engine_id": "DOCS_ENGINE"
})

Configuration Validation

Skills validate configuration in setup():

┌─────────────────────────────────────────────────────────────────────────────┐
│                      Validation Flow                                        │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                             │
│  1. add_skill() called with params                                          │
│              │                                                              │
│              ▼                                                              │
│  2. Skill instantiated                                                      │
│     • params stored in self.params                                          │
│     • swaig_fields extracted                                                │
│              │                                                              │
│              ▼                                                              │
│  3. setup() called                                                          │
│     • validate_packages() - check Python packages                           │
│     • validate_env_vars() - check environment                               │
│     • Custom validation                                                     │
│              │                                                              │
│              ▼                                                              │
│  4. Success: register_tools() called                                        │
│     Failure: ValueError raised                                              │
│                                                                             │
└─────────────────────────────────────────────────────────────────────────────┘

Complete Configuration Example

from signalwire_agents import AgentBase
from signalwire_agents.skills.registry import skill_registry
import os


## Register external skills
skill_registry.add_skill_directory("/opt/my_company/skills")


class ConfiguredAgent(AgentBase):
    def __init__(self):
        super().__init__(name="configured-agent")
        self.add_language("English", "en-US", "rime.spore")

        # Simple skill - no config
        self.add_skill("datetime")

        # Skill with parameters
        self.add_skill("web_search", {
            "api_key": os.getenv("GOOGLE_API_KEY"),
            "search_engine_id": os.getenv("SEARCH_ENGINE_ID"),
            "num_results": 5,
            "min_quality_score": 0.4
        })

        # Skill with SWAIG field overrides
        self.add_skill("math", {
            "swaig_fields": {
                "fillers": {
                    "en-US": ["Calculating..."]
                }
            }
        })

        # Multi-instance skill
        self.add_skill("native_vector_search", {
            "tool_name": "search_products",
            "index_path": "/data/products.swsearch"
        })

        self.add_skill("native_vector_search", {
            "tool_name": "search_faqs",
            "index_path": "/data/faqs.swsearch"
        })

        self.prompt_add_section(
            "Role",
            "You are a customer service agent."
        )


if __name__ == "__main__":
    agent = ConfiguredAgent()
    agent.run()

Configuration Best Practices

Security

• Store API keys in environment variables
• Never commit secrets to version control
• Use hidden: true for sensitive parameters

Organization

• Group related configuration
• Use descriptive tool_name for multi-instance
• Document required configuration

Validation

• Check has_skill() before using conditionally
• Handle ValueError from add_skill()
• Validate parameters early in setup()

Next Steps

You've learned the complete skills system. Next, explore advanced topics like contexts, workflows, and state management.
