Mapping Numbers

Mapping Numbers

Summary: Connect phone numbers to your agent's SWML endpoint so calls are handled by your agent.

Overview

┌─────────────────────────────────────────────────────────────────────────────┐
│                      Number to Agent Mapping                                │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                             │
│  Phone Number          →    Voice URL           →    Agent                  │
│  +1 (555) 123-4567          https://server/          SupportAgent           │
│  +1 (555) 987-6543          https://server/sales     SalesAgent             │
│                                                                             │
│  When a call comes in:                                                      │
│  1. SignalWire receives call on your number                                 │
│  2. SignalWire makes POST request to Voice URL                              │
│  3. Your server returns SWML document                                       │
│  4. SignalWire executes the SWML (runs your agent)                          │
│                                                                             │
└─────────────────────────────────────────────────────────────────────────────┘

Configure Voice URL

1. Go to Phone Numbers in dashboard
2. Click on your number
3. Set Voice URL to your agent endpoint
4. Save changes

URL Format

Your agent URL structure:

Single Agent:

https://your-server.com/

Multiple Agents:

https://your-server.com/support
https://your-server.com/sales
https://your-server.com/billing

With Authentication:

https://user:pass@your-server.com/

HTTPS Requirements

Production:

• HTTPS required
• Valid SSL certificate
• Properly configured domain

Development:

• Use ngrok or similar tunnel
• ngrok provides HTTPS automatically
• Update URL when tunnel restarts

Using ngrok for Development

## Start your agent locally
python my_agent.py

## In another terminal, start ngrok
ngrok http 3000

## Use the ngrok HTTPS URL in SignalWire
## https://abc123.ngrok.io

Basic Authentication

Set authentication credentials:

from signalwire_agents import AgentBase


class SecureAgent(AgentBase):
    def __init__(self):
        super().__init__(
            name="secure-agent",
            # Basic auth credentials
            # Also configurable via environment variables:
            # SWML_BASIC_AUTH_USER, SWML_BASIC_AUTH_PASSWORD
        )

In SignalWire, use URL with credentials:

https://username:password@your-server.com/

Multi-Agent Server

Run multiple agents on one server:

from signalwire_agents import AgentServer

server = AgentServer()

## Register agents at different paths
server.register(SupportAgent(), "/support")
server.register(SalesAgent(), "/sales")
server.register(BillingAgent(), "/billing")

server.run(host="0.0.0.0", port=3000)

Map each number to its agent:

Number	Voice URL
+1 (555) 111-1111	https://server.com/support
+1 (555) 222-2222	https://server.com/sales
+1 (555) 333-3333	https://server.com/billing

SWML Scripts

Alternative: Use SWML scripts directly in SignalWire:

{
    "version": "1.0.0",
    "sections": {
        "main": [
            {
                "ai": {
                    "prompt": {
                        "text": "You are a helpful assistant."
                    },
                    "SWAIG": {
                        "defaults": {
                            "web_hook_url": "https://your-server.com/swaig"
                        }
                    }
                }
            }
        ]
    }
}

Fallback URL

Configure a fallback for errors:

Setting	Value
Primary URL	https://your-server.com/agent
Fallback URL	https://backup-server.com/agent

Fallback triggers on:

• Connection timeout
• HTTP 5xx errors
• Invalid SWML response

Status Callbacks

Receive notifications about call events:

Status Callback URL: https://your-server.com/status

Events:
• Call started
• Call answered
• Call completed
• Call failed

Verification Checklist

Before going live:

• Agent is deployed and running
• HTTPS URL is accessible
• URL returns valid SWML on POST request
• Basic auth is configured (if used)
• Phone number Voice URL is set
• Fallback URL is configured (recommended)
• Test call completes successfully
