Exposing Agents

Exposing Your Agent to the Internet​

Summary: Use ngrok to create a public URL for your local agent so SignalWire can send webhook requests to it.

Why You Need a Public URL​

SignalWire's cloud needs to reach your agent via HTTP:

┌─────────────────────────────────────────────────────────────────────────────┐
│                         The Problem                                         │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                             │
│  SignalWire Cloud                        Your Computer                      │
│  ┌─────────────────┐                    ┌─────────────────┐                 │
│  │                 │                    │                 │                 │
│  │  Needs to send  │     CANNOT         │  localhost:3000 │                 │
│  │  HTTP requests  │ ───── X ─────────► │                 │                 │
│  │                 │     REACH          │  (Not on the    │                 │
│  └─────────────────┘                    │   internet)     │                 │
│                                         └─────────────────┘                 │
│                                                                             │
└─────────────────────────────────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────────────────────────────────┐
│                         The Solution: ngrok                                 │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                             │
│  SignalWire Cloud        ngrok Cloud           Your Computer                │
│  ┌─────────────────┐    ┌─────────────────┐   ┌─────────────────┐           │
│  │                 │    │                 │   │                 │           │
│  │  Sends request  │───►│  abc123.ngrok.io│──►│  localhost:3000 │           │
│  │  to public URL  │    │  (tunnel)       │   │                 │           │
│  │                 │◄───│                 │◄──│                 │           │
│  └─────────────────┘    └─────────────────┘   └─────────────────┘           │
│                                                                             │
│  https://abc123.ngrok.io  ───►  tunnels to  ───►  http://localhost:3000     │
│                                                                             │
└─────────────────────────────────────────────────────────────────────────────┘

Installing ngrok​

macOS (Homebrew)​

brew install ngrok

Linux​

## Download
curl -s https://ngrok-agent.s3.amazonaws.com/ngrok.asc | \
  sudo tee /etc/apt/trusted.gpg.d/ngrok.asc >/dev/null && \
  echo "deb https://ngrok-agent.s3.amazonaws.com buster main" | \
  sudo tee /etc/apt/sources.list.d/ngrok.list

## Install
sudo apt update && sudo apt install ngrok

Windows​

## Using Chocolatey
choco install ngrok

## Or download from https://ngrok.com/download

Direct Download​

Visit ngrok.com/download and download for your platform.

Create an ngrok Account (Free)​

  1. Go to ngrok.com and sign up
  2. Get your auth token from the dashboard
  3. Configure ngrok with your token:
ngrok config add-authtoken YOUR_AUTH_TOKEN_HERE

This enables:

  • Longer session times
  • Custom subdomains (paid)
  • Multiple tunnels

Basic Usage​

Start your agent in one terminal:

## Terminal 1
python my_agent.py

Start ngrok in another terminal:

## Terminal 2
ngrok http 3000

You'll see output like:

ngrok                                                           (Ctrl+C to quit)

Session Status                online
Account                       your-email@example.com (Plan: Free)
Version                       3.x.x
Region                        United States (us)
Latency                       45ms
Web Interface                 http://127.0.0.1:4040
Forwarding                    https://abc123def456.ngrok-free.app -> http://localhost:3000

Connections                   ttl     opn     rt1     rt5     p50     p90
                              0       0       0.00    0.00    0.00    0.00

Your public URL is: https://abc123def456.ngrok-free.app

Test the Tunnel​

## Test locally
curl http://localhost:3000/

## Test through ngrok (use YOUR URL from ngrok output)
curl https://abc123def456.ngrok-free.app/

Both should return the same SWML document.

ngrok Web Interface​

ngrok provides a web interface at http://127.0.0.1:4040 showing:

  • All requests coming through the tunnel
  • Request/response headers and bodies
  • Timing information
  • Ability to replay requests

This is invaluable for debugging SignalWire webhook calls!

Free ngrok gives you random URLs that change each restart. For easier development, use a static domain:

Free Static Domain (ngrok account required)​

  1. Go to ngrok Dashboard → Domains
  2. Create a free static domain (e.g., your-name.ngrok-free.app)
  3. Use it:
ngrok http 3000 --domain=your-name.ngrok-free.app

Now your URL stays the same across restarts!

Understanding Basic Authentication​

Important: The SDK automatically secures your agent with HTTP Basic Authentication. Every time you start your agent, you'll see:

Agent 'my-agent' is available at:
URL: http://localhost:3000
Basic Auth: signalwire:7vVZ8iMTOWL0Y7-BG6xaN3qhjmcm4Sf59nORNdlF9bs (source: provided)

The password changes on every restart unless you set environment variables.

Setting Persistent Credentials​

For development, set these environment variables to use the same credentials across restarts:

## In your .env file or shell
export SWML_BASIC_AUTH_USER=signalwire
export SWML_BASIC_AUTH_PASSWORD=your-secure-password-here

Then start your agent:

python my_agent.py

Now it will show:

Basic Auth: signalwire:your-secure-password-here (source: environment)

Why this matters:

  • SignalWire needs these credentials to call your agent
  • Random passwords mean reconfiguring SignalWire on every restart
  • Set environment variables once for consistent development

Configure Your Agent for ngrok​

Set the SWML_PROXY_URL_BASE environment variable so your agent generates correct webhook URLs:

## In your .env file
SWML_PROXY_URL_BASE=https://your-name.ngrok-free.app
SWML_BASIC_AUTH_USER=signalwire
SWML_BASIC_AUTH_PASSWORD=your-secure-password-here

Or set them when running:

SWML_PROXY_URL_BASE=https://your-name.ngrok-free.app \
SWML_BASIC_AUTH_USER=signalwire \
SWML_BASIC_AUTH_PASSWORD=your-secure-password-here \
python my_agent.py

This ensures:

  • SWAIG function webhook URLs point to your public ngrok URL, not localhost
  • Authentication credentials remain consistent across restarts

Complete Development Setup​

Here's the full workflow:

## Terminal 1: Start ngrok with static domain
ngrok http 3000 --domain=your-name.ngrok-free.app

## Terminal 2: Start agent with environment variables
export SWML_PROXY_URL_BASE=https://your-name.ngrok-free.app
export SWML_BASIC_AUTH_USER=signalwire
export SWML_BASIC_AUTH_PASSWORD=your-secure-password-here
python my_agent.py

## Terminal 3: Test (use the credentials from Terminal 2)
curl -u signalwire:your-secure-password-here https://your-name.ngrok-free.app/
curl -u signalwire:your-secure-password-here https://your-name.ngrok-free.app/debug

Using a Script​

Create start-dev.sh:

#!/bin/bash
## start-dev.sh - Start development environment

NGROK_DOMAIN="your-name.ngrok-free.app"
AUTH_USER="signalwire"
AUTH_PASS="your-secure-password-here"

echo "Starting development environment..."
echo "Public URL: https://${NGROK_DOMAIN}"
echo "Basic Auth: ${AUTH_USER}:${AUTH_PASS}"
echo ""

## Start ngrok in background
ngrok http 3000 --domain=${NGROK_DOMAIN} &
NGROK_PID=$!

## Wait for ngrok to start
sleep 2

## Start agent with environment variables
export SWML_PROXY_URL_BASE="https://${NGROK_DOMAIN}"
export SWML_BASIC_AUTH_USER="${AUTH_USER}"
export SWML_BASIC_AUTH_PASSWORD="${AUTH_PASS}"
python my_agent.py

## Cleanup on exit
trap "kill $NGROK_PID 2>/dev/null" EXIT

Make it executable:

chmod +x start-dev.sh
./start-dev.sh

Alternative Tunneling Solutions​

Cloudflare Tunnel (Free)​

## Install cloudflared
brew install cloudflared  # macOS

## Quick tunnel (no account needed)
cloudflared tunnel --url http://localhost:3000

localtunnel (Free, no signup)​

## Install
npm install -g localtunnel

## Run
lt --port 3000

tailscale Funnel (Requires Tailscale)​

## If you use Tailscale
tailscale funnel 3000

Production Alternatives​

For production, don't use ngrok. Instead:

OptionDescription
Cloud VMDeploy to AWS, GCP, Azure, DigitalOcean
ServerlessAWS Lambda, Google Cloud Functions, Azure Functions
ContainerDocker on Kubernetes, ECS, Cloud Run
VPSAny server with a public IP

See the Deployment chapter for production deployment guides.

Troubleshooting​

ngrok shows "ERR_NGROK_108"​

Your auth token is invalid or expired. Get a new one from the ngrok dashboard:

ngrok config add-authtoken YOUR_NEW_TOKEN

Connection refused​

Your agent isn't running or is on a different port:

## Check agent is running
curl http://localhost:3000/

## If using different port
ngrok http 8080

Webhook URLs still show localhost​

Set SWML_PROXY_URL_BASE:

export SWML_PROXY_URL_BASE=https://your-domain.ngrok-free.app
python my_agent.py

ngrok tunnel expires​

Free ngrok tunnels expire after a few hours. Solutions:

  • Restart ngrok
  • Use a static domain (stays same after restart)
  • Upgrade to paid ngrok plan
  • Use an alternative like Cloudflare Tunnel

What's Next?​

Your agent is now accessible at a public URL. You're ready to connect it to SignalWire!

You've Completed Phase 1!​

  • Installed the SDK
  • Created your first agent
  • Set up development environment
  • Exposed agent via ngrok

Your agent is ready at: https://your-domain.ngrok-free.app

Next Chapter: Core Concepts - Deep dive into SWML, SWAIG, and agent architecture

Or jump to: SignalWire Integration - Connect your agent to phone numbers
