CGI Mode​

Summary: Deploy agents as CGI scripts on traditional web servers like Apache or nginx. The SDK automatically detects CGI environments and handles requests appropriately.

CGI Overview​

CGI (Common Gateway Interface) allows web servers to execute scripts and return their output as HTTP responses.

Benefits:

  • Works with shared hosting
  • Simple deployment - just upload files
  • No separate process management
  • Compatible with Apache, nginx

Drawbacks:

  • New process per request (slower)
  • No persistent connections
  • Limited scalability

CGI Detection​

The SDK detects CGI mode via the GATEWAY_INTERFACE environment variable:

## Automatic detection
if os.getenv('GATEWAY_INTERFACE'):
    # CGI mode detected
    mode = 'cgi'

Basic CGI Script​

#!/usr/bin/env python3
## agent.py - Basic CGI agent script
from signalwire_agents import AgentBase


class MyAgent(AgentBase):
    def __init__(self):
        super().__init__(name="my-agent")
        self.add_language("English", "en-US", "rime.spore")
        self.prompt_add_section("Role", "You are a helpful assistant.")


if __name__ == "__main__":
    agent = MyAgent()
    agent.run()  # Automatically detects CGI mode

Make it executable:

chmod +x agent.py

CGI Request Flow​

┌─────────────────────────────────────────────────────────────────────────────┐
│                     CGI Request Flow                                        │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                             │
│  SignalWire                                                                 │
│      │                                                                      │
│      ▼                                                                      │
│  ┌──────────────────┐                                                       │
│  │   Web Server     │  Apache/nginx                                         │
│  │   (httpd)        │                                                       │
│  └──────────────────┘                                                       │
│      │                                                                      │
│      │  Sets environment variables:                                         │
│      │  • GATEWAY_INTERFACE=CGI/1.1                                         │
│      │  • PATH_INFO=/swaig                                                  │
│      │  • CONTENT_LENGTH=...                                                │
│      │                                                                      │
│      ▼                                                                      │
│  ┌──────────────────┐                                                       │
│  │   Python CGI     │  agent.py                                             │
│  │   Script         │                                                       │
│  └──────────────────┘                                                       │
│      │                                                                      │
│      │  PATH_INFO=""     → Return SWML document                             │
│      │  PATH_INFO=/swaig → Execute SWAIG function                           │
│      │                                                                      │
│      ▼                                                                      │
│  ┌──────────────────┐                                                       │
│  │   stdout         │  JSON response to web server                          │
│  └──────────────────┘                                                       │
│                                                                             │
└─────────────────────────────────────────────────────────────────────────────┘

Apache Configuration​

Enable CGI​

## Enable CGI module
LoadModule cgi_module modules/mod_cgi.so

## Configure CGI directory
<Directory "/var/www/cgi-bin">
    Options +ExecCGI
    AddHandler cgi-script .py
    Require all granted
</Directory>

Virtual Host Configuration​

<VirtualHost *:443>
    ServerName agent.example.com

    SSLEngine on
    SSLCertificateFile /etc/ssl/certs/agent.crt
    SSLCertificateKeyFile /etc/ssl/private/agent.key

    ScriptAlias / /var/www/cgi-bin/agent.py

    <Directory "/var/www/cgi-bin">
        Options +ExecCGI
        SetHandler cgi-script
        Require all granted
    </Directory>

    # Set environment variables
    SetEnv SWML_BASIC_AUTH_USER "myuser"
    SetEnv SWML_BASIC_AUTH_PASSWORD "mypassword"
</VirtualHost>

nginx Configuration​

nginx doesn't natively support CGI, but you can use FastCGI with fcgiwrap:

server {
    listen 443 ssl;
    server_name agent.example.com;

    ssl_certificate /etc/ssl/certs/agent.crt;
    ssl_certificate_key /etc/ssl/private/agent.key;

    location / {
        fastcgi_pass unix:/var/run/fcgiwrap.socket;
        fastcgi_param SCRIPT_FILENAME /var/www/cgi-bin/agent.py;
        fastcgi_param GATEWAY_INTERFACE CGI/1.1;
        fastcgi_param PATH_INFO $uri;
        fastcgi_param SWML_BASIC_AUTH_USER "myuser";
        fastcgi_param SWML_BASIC_AUTH_PASSWORD "mypassword";
        include fastcgi_params;
    }
}

CGI Host Configuration​

In CGI mode, the SDK needs to know the external hostname for generating URLs:

## Using swaig-test to simulate CGI mode
swaig-test my_agent.py --simulate-serverless cgi --cgi-host agent.example.com

Or set environment variable:

SetEnv SWML_PROXY_URL_BASE "https://agent.example.com"

Testing CGI Locally​

Use swaig-test to simulate CGI environment:

## Test SWML generation in CGI mode
swaig-test my_agent.py --simulate-serverless cgi --dump-swml

## With custom host
swaig-test my_agent.py --simulate-serverless cgi --cgi-host mysite.com --dump-swml

## Test a function
swaig-test my_agent.py --simulate-serverless cgi --exec function_name --param value

Authentication in CGI Mode​

The SDK checks basic auth in CGI mode:

## Authentication is automatic when these are set
## SWML_BASIC_AUTH_USER
## SWML_BASIC_AUTH_PASSWORD

## The SDK reads Authorization header and validates

If authentication fails, returns 401 with WWW-Authenticate header.

Directory Structure​

/var/www/cgi-bin/
├── agent.py              # Main CGI script
├── requirements.txt      # Dependencies
└── venv/                 # Virtual environment (optional)

Shared Hosting Deployment​

For shared hosting where you can't install system packages:

#!/usr/bin/env python3
## agent_shared.py - CGI agent for shared hosting
import sys
import os

## Add local packages directory
sys.path.insert(0, os.path.join(os.path.dirname(__file__), 'packages'))

from signalwire_agents import AgentBase


class MyAgent(AgentBase):
    def __init__(self):
        super().__init__(name="my-agent")
        self.add_language("English", "en-US", "rime.spore")


if __name__ == "__main__":
    agent = MyAgent()
    agent.run()

Install packages locally:

pip install --target=./packages signalwire-agents

CGI Best Practices​

Performance​

  • Keep imports minimal - each request starts fresh
  • Consider FastCGI for better performance
  • Cache what you can (but remember process dies)

Security​

  • Set proper file permissions (750 or 755)
  • Don't expose .py files directly if possible
  • Use HTTPS always
  • Set auth credentials as environment variables

Debugging​

  • Check web server error logs
  • Verify shebang line (#!/usr/bin/env python3)
  • Test script from command line first
  • Ensure proper line endings (LF, not CRLF)

Common CGI Issues​

IssueSolution
500 Internal Server ErrorCheck error logs, verify permissions
Permission deniedchmod +x agent.py
Module not foundCheck sys.path, install dependencies
Wrong Python versionUpdate shebang to correct Python
Malformed headersEnsure proper Content-Type output
TimeoutOptimize code, increase server timeout

Migration from CGI​

When you outgrow CGI:

CGI → FastCGI​

Keep same code, use fcgiwrap or gunicorn. Better performance, persistent processes.

CGI → Server Mode​

Same code works - just run differently (python agent.py instead of CGI). Add systemd service, nginx reverse proxy.

CGI → Serverless​

Same code works with minor changes. Add Lambda handler wrapper. Deploy to AWS/GCP/Azure.
