Call Flow Customization

Summary: Control call flow with verb insertion points for pre-answer, post-answer, and post-AI actions.

Understanding Call Flow

By default, AgentBase generates a simple call flow:

answer → ai

The SDK provides three insertion points to customize this flow:

┌─────────────────────────────────────────────────────────────────┐
│  PRE-ANSWER VERBS (call still ringing)                          │
│  • Ringback tones, call screening, conditional routing          │
└─────────────────────────────────────────────────────────────────┘
                              │
                              ▼
┌─────────────────────────────────────────────────────────────────┐
│  ANSWER VERB (call connected)                                   │
│  • Automatic when auto_answer=True (default)                    │
└─────────────────────────────────────────────────────────────────┘
                              │
                              ▼
┌─────────────────────────────────────────────────────────────────┐
│  POST-ANSWER VERBS (before AI)                                  │
│  • Welcome messages, disclaimers, hold music                    │
└─────────────────────────────────────────────────────────────────┘
                              │
                              ▼
┌─────────────────────────────────────────────────────────────────┐
│  AI VERB (conversation)                                         │
└─────────────────────────────────────────────────────────────────┘
                              │
                              ▼
┌─────────────────────────────────────────────────────────────────┐
│  POST-AI VERBS (after conversation)                             │
│  • Cleanup, transfers, surveys, logging                         │
└─────────────────────────────────────────────────────────────────┘

Verb Insertion Methods

Method	Purpose	Common Uses
`add_pre_answer_verb()`	Before answering	Ringback, screening, routing
`add_post_answer_verb()`	After answer, before AI	Announcements, disclaimers
`add_post_ai_verb()`	After AI ends	Cleanup, transfers, surveys

Pre-Answer Verbs

Pre-answer verbs run while the call is still ringing. Use them for:

Ringback tones: Play audio before answering
Call screening: Check caller ID or time
Conditional routing: Route based on variables

#!/usr/bin/env python3
from signalwire_agents import AgentBase


class RingbackAgent(AgentBase):
    """Agent that plays ringback tone before answering."""

    def __init__(self):
        super().__init__(name="ringback", port=3000)

        # Play US ringback tone before answering
        # IMPORTANT: auto_answer=False prevents play from answering the call
        self.add_pre_answer_verb("play", {
            "urls": ["ring:us"],
            "auto_answer": False
        })

        # Configure AI
        self.add_language("English", "en-US", "rime.spore")
        self.prompt_add_section("Role", "You are a helpful assistant.")


if __name__ == "__main__":
    agent = RingbackAgent()
    agent.run()

Generated SWML:

{
  "sections": {
    "main": [
      {"play": {"urls": ["ring:us"], "auto_answer": false}},
      {"answer": {}},
      {"ai": {...}}
    ]
  }
}

Pre-Answer Safe Verbs

Only certain verbs can run before the call is answered:

Verb	Pre-Answer Safe	Notes
`play`	Yes*	Requires `auto_answer: false`
`connect`	Yes*	Requires `auto_answer: false`
`sleep`	Yes	Wait for duration
`set`	Yes	Set variables
`request`	Yes	HTTP request
`switch`	Yes	Variable-based branching
`cond`	Yes	Conditional branching
`if`	Yes	If/then/else
`eval`	Yes	Evaluate expressions
`goto`	Yes	Jump to label
`label`	Yes	Define jump target
`hangup`	Yes	Reject call
`transfer`	Yes	Route elsewhere

*These verbs auto-answer by default. Set auto_answer: false for pre-answer use.

Available Ringback Tones

Tone	Description
`ring:us`	US ringback tone
`ring:uk`	UK ringback tone
`ring:it`	Italian ringback tone
`ring:at`	Austrian ringback tone

Post-Answer Verbs

Post-answer verbs run after the call is connected but before the AI speaks:

#!/usr/bin/env python3
from signalwire_agents import AgentBase


class WelcomeAgent(AgentBase):
    """Agent that plays welcome message before AI."""

    def __init__(self):
        super().__init__(name="welcome", port=3000)

        # Play welcome announcement
        self.add_post_answer_verb("play", {
            "url": "say:Thank you for calling Acme Corporation. "
                   "Your call may be recorded for quality assurance."
        })

        # Brief pause before AI speaks
        self.add_post_answer_verb("sleep", {"time": 500})

        # Configure AI
        self.add_language("English", "en-US", "rime.spore")
        self.prompt_add_section(
            "Role",
            "You are a customer service representative. "
            "The caller has just heard the welcome message."
        )


if __name__ == "__main__":
    agent = WelcomeAgent()
    agent.run()

Generated SWML:

{
  "sections": {
    "main": [
      {"answer": {}},
      {"play": {"url": "say:Thank you for calling..."}},
      {"sleep": {"time": 500}},
      {"ai": {...}}
    ]
  }
}

Common Post-Answer Uses

Use Case	Example
Welcome message	`{"url": "say:Thank you for calling..."}`
Legal disclaimer	`{"url": "say:This call may be recorded..."}`
Hold music	`{"url": "https://example.com/hold.mp3"}`
Pause	`{"time": 500}` (milliseconds)
Recording	Use `record_call=True` in constructor

Post-AI Verbs

Post-AI verbs run after the AI conversation ends:

#!/usr/bin/env python3
from signalwire_agents import AgentBase


class SurveyAgent(AgentBase):
    """Agent that logs call outcome after conversation."""

    def __init__(self):
        super().__init__(name="survey", port=3000)

        # Configure AI
        self.add_language("English", "en-US", "rime.spore")
        self.prompt_add_section("Role", "You are a support agent.")

        # After AI ends, log the call and hang up
        self.add_post_ai_verb("request", {
            "url": "https://api.example.com/call-complete",
            "method": "POST"
        })
        self.add_post_ai_verb("hangup", {})


if __name__ == "__main__":
    agent = SurveyAgent()
    agent.run()

Common Post-AI Uses

Use Case	Verb	Example
Clean disconnect	`hangup`	`{}`
Transfer to human	`transfer`	`{"dest": "tel:+15551234567"}`
Post-call survey	`prompt`	DTMF collection
Log outcome	`request`	HTTP POST to API
Connect to queue	`enter_queue`	`{"name": "support"}`

Complete Example

Here's an agent with all three insertion points:

#!/usr/bin/env python3
from signalwire_agents import AgentBase


class CallFlowAgent(AgentBase):
    """Agent demonstrating complete call flow customization."""

    def __init__(self):
        super().__init__(name="call-flow", port=3000)

        # PRE-ANSWER: Ringback tone
        self.add_pre_answer_verb("play", {
            "urls": ["ring:us"],
            "auto_answer": False
        })

        # POST-ANSWER: Welcome and disclaimer
        self.add_post_answer_verb("play", {
            "url": "say:Welcome to Acme Corporation."
        })
        self.add_post_answer_verb("play", {
            "url": "say:This call may be recorded for quality assurance."
        })
        self.add_post_answer_verb("sleep", {"time": 500})

        # Configure AI
        self.add_language("English", "en-US", "rime.spore")
        self.prompt_add_section(
            "Role",
            "You are a friendly customer service representative. "
            "The caller has just heard the welcome message."
        )
        self.set_params({
            "end_of_speech_timeout": 1000,
            "attention_timeout": 10000
        })

        # POST-AI: Clean disconnect
        self.add_post_ai_verb("hangup", {})


if __name__ == "__main__":
    agent = CallFlowAgent()
    agent.run()

Generated SWML:

{
  "sections": {
    "main": [
      {"play": {"urls": ["ring:us"], "auto_answer": false}},
      {"answer": {}},
      {"play": {"url": "say:Welcome to Acme Corporation."}},
      {"play": {"url": "say:This call may be recorded..."}},
      {"sleep": {"time": 500}},
      {"ai": {...}},
      {"hangup": {}}
    ]
  }
}

Controlling Answer Behavior

Disable Auto-Answer

Set auto_answer=False to prevent automatic answering:

class ManualAnswerAgent(AgentBase):
    def __init__(self):
        # Disable auto-answer
        super().__init__(name="manual", port=3000, auto_answer=False)

        # Pre-answer: Play ringback
        self.add_pre_answer_verb("play", {
            "urls": ["ring:us"],
            "auto_answer": False
        })

        # Note: Without auto_answer, the AI will start without
        # explicitly answering. Use add_answer_verb() if you need
        # to answer at a specific point.

Customize Answer Verb

Use add_answer_verb() to configure the answer verb:

# Set max call duration to 1 hour
agent.add_answer_verb({"max_duration": 3600})

Dynamic Call Flow

Modify call flow based on caller information using on_swml_request():

class DynamicFlowAgent(AgentBase):
    def __init__(self):
        super().__init__(name="dynamic", port=3000)
        self.add_language("English", "en-US", "rime.spore")
        self.prompt_add_section("Role", "You are a receptionist.")

        # VIP numbers get special treatment
        self.vip_numbers = ["+15551234567", "+15559876543"]

    def on_swml_request(self, request_data=None, callback_path=None, request=None):
        call_data = (request_data or {}).get("call", {})
        caller = call_data.get("from", "")

        if caller in self.vip_numbers:
            # VIP: No ringback, immediate welcome
            self.clear_pre_answer_verbs()
            self.add_post_answer_verb("play", {
                "url": "say:Welcome back, valued customer!"
            })
        else:
            # Regular caller: Ringback tone
            self.add_pre_answer_verb("play", {
                "urls": ["ring:us"],
                "auto_answer": False
            })

Clear Methods

Remove verbs from insertion points:

agent.clear_pre_answer_verbs()   # Remove all pre-answer verbs
agent.clear_post_answer_verbs()  # Remove all post-answer verbs
agent.clear_post_ai_verbs()      # Remove all post-AI verbs

Method Chaining

All verb insertion methods return self for chaining:

agent = AgentBase(name="chained", port=3000)
agent.add_pre_answer_verb("play", {"urls": ["ring:us"], "auto_answer": False}) \
     .add_post_answer_verb("play", {"url": "say:Welcome"}) \
     .add_post_answer_verb("sleep", {"time": 500}) \
     .add_post_ai_verb("hangup", {})
