Building Agents
Summary: Learn how to build voice AI agents using AgentBase, from basic configuration to advanced prompt engineering and voice customization.
What You'll Learn
This chapter covers everything you need to build production-quality agents:
- AgentBase - The foundation class and its capabilities
- Static vs Dynamic - Choosing the right pattern for your use case
- Prompts & POM - Crafting effective prompts with the Prompt Object Model
- Voice & Language - Configuring voices and multi-language support
- AI Parameters - Tuning conversation behavior
- Hints - Improving speech recognition accuracy
- Call Flow - Customizing when and how calls are answered
Prerequisites
Before building agents, you should understand:
- Core concepts from Chapter 2 (SWML, SWAIG, Lifecycle)
- Basic Python class structure
- How SignalWire processes calls
Agent Architecture Overview
┌─────────────────────────────────────────────────────────────────────────────┐
│ Agent Components │
├─────────────────────────────────────────────────────────────────────────────┤
│ │
│ ┌───────────────────────────────────────────────────────────────────┐ │
│ │ Your Agent Class │ │
│ │ (extends AgentBase) │ │
│ └───────────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌───────────────────────────────────────────────────────────────────┐ │
│ │ Configuration │ │
│ ├───────────────────────────────────────────────────────────────────┤ │
│ │ │ │
│ │ ┌─────────────┐ ┌─────────────┐ ┌─────────────┐ │ │
│ │ │ Prompts │ │ Voice │ │ AI Params │ │ │
│ │ ├─────────────┤ ├─────────────┤ ├─────────────┤ │ │
│ │ │ • Role │ │ • Language │ │ • Timeouts │ │ │
│ │ │ • Guidelines│ │ • Voice │ │ • Barge │ │ │
│ │ │ • Rules │ │ • TTS Engine│ │ • Attention │ │ │
│ │ └─────────────┘ └─────────────┘ └─────────────┘ │ │
│ │ │ │
│ │ ┌─────────────┐ ┌─────────────┐ ┌───────────────┐ │ │
│ │ │ Hints │ │ Functions │ │ Skills │ │ │
│ │ ├─────────────┤ ├─────────────┤ ├───────────────┤ │ │
│ │ │ • Keywords │ │ • Tools │ │ • Plugins │ │ │
│ │ │ • Names │ │ • DataMap │ │ • Add-ons │ │ │
│ │ │ • Terms │ │ • Handlers │ │ • Integrations│ │ │
│ │ └─────────────┘ └─────────────┘ └───────────────┘ │ │
│ └───────────────────────────────────────────────────────────────────┘ │
│ │ │
│ ▼ │
│ ┌───────────────────────────────────────────────────────────────────┐ │
│ │ SWML Output │ │
│ │ (Generated automatically) │ │
│ └───────────────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────────────┘
A Complete Agent Example
Here's what a production agent looks like:
from signalwire_agents import AgentBase, SwaigFunctionResult
class CustomerSupportAgent(AgentBase):
"""Production customer support agent."""
def __init__(self):
super().__init__(
name="customer-support",
route="/support"
)
# Voice configuration
self.add_language("English", "en-US", "rime.spore")
# AI behavior
self.set_params({
"end_of_speech_timeout": 500,
"attention_timeout": 15000,
"inactivity_timeout": 30000
})
# Prompts
self.prompt_add_section(
"Role",
"You are Alex, a friendly customer support agent for Acme Inc."
)
self.prompt_add_section(
"Guidelines",
body="Follow these guidelines:",
bullets=[
"Be helpful and professional",
"Ask clarifying questions when needed",
"Keep responses concise for voice",
"Offer to transfer if you cannot help"
]
)
# Speech recognition hints
self.add_hints([
"Acme", "account number", "order status",
"refund", "billing", "representative"
])
# Functions
self.define_tool(
name="check_order",
description="Look up an order by order number",
parameters={
"type": "object",
"properties": {
"order_number": {
"type": "string",
"description": "The order number to look up"
}
},
"required": ["order_number"]
},
handler=self.check_order
)
# Skills
self.add_skill("datetime")
# Post-call summary
self.set_post_prompt(
"Summarize: issue type, resolution, customer satisfaction"
)
def check_order(self, args, raw_data):
order_number = args.get("order_number")
# Your business logic here
return SwaigFunctionResult(
f"Order {order_number}: Shipped on Monday, arriving Thursday"
)
if __name__ == "__main__":
agent = CustomerSupportAgent()
agent.run(host="0.0.0.0", port=3000)
Chapter Contents
| Section | Description |
|---|---|
| AgentBase | Core class and constructor options |
| Static vs Dynamic | Choosing the right pattern |
| Prompts & POM | Prompt engineering for voice AI |
| Voice & Language | Voice selection and multi-language |
| AI Parameters | Behavior tuning |
| Hints | Speech recognition improvement |
| Call Flow | Customizing call answer behavior |
Key Patterns
Pattern 1: Class-Based Agent
Best for complex agents with multiple functions:
class MyAgent(AgentBase):
def __init__(self):
super().__init__(name="my-agent")
self.configure()
def configure(self):
# All configuration here
pass
Pattern 2: Functional Agent
Quick agents for simple use cases:
from signalwire_agents import AgentBase
agent = AgentBase(name="simple-agent")
agent.add_language("English", "en-US", "rime.spore")
agent.prompt_add_section("Role", "You are a helpful assistant.")
agent.run()
Pattern 3: Multi-Agent Server
Multiple agents on one server:
from signalwire_agents import AgentServer
server = AgentServer()
server.register(SupportAgent(), "/support")
server.register(SalesAgent(), "/sales")
server.register(BillingAgent(), "/billing")
server.run(port=3000)
Testing Your Agent
Always test before deploying:
# View SWML output
swaig-test my_agent.py --dump-swml
# List registered functions
swaig-test my_agent.py --list-tools
# Test a function
swaig-test my_agent.py --exec check_order --order_number 12345
Let's start with understanding AgentBase in depth.
Class Overview
┌─────────────────────────────────────────────────────────────────────────────┐
│ AgentBase Inheritance │
├─────────────────────────────────────────────────────────────────────────────┤
│ │
│ AgentBase │
│ │ │
│ ┌─────────────────┼────────────────┐ │
│ │ │ │ │
│ ▼ ▼ ▼ │
│ ┌──────────┐ ┌──────────┐ ┌───────────┐ │
│ │ AuthMixin│ │ WebMixin │ │SWMLService│ │
│ └──────────┘ └──────────┘ └───────────┘ │
│ │
│ ┌───────────┐ ┌──────────┐ ┌──────────┐ │
│ │PromptMixin│ │ ToolMixin│ │SkillMixin│ │
│ └───────────┘ └──────────┘ └──────────┘ │
│ │
│ ┌─────────────┐ ┌───────────────┐ │
│ │AIConfigMixin│ │ServerlessMixin│ │
│ └─────────────┘ └───────────────┘ │
│ │
│ ┌──────────┐ │
│ │StateMixin│ │
│ └──────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────────────┘
Constructor Parameters
from signalwire_agents import AgentBase
agent = AgentBase(
# Required
name="my-agent", # Unique agent identifier
# Server Configuration
route="/", # HTTP route path (default: "/")
host="0.0.0.0", # Bind address (default: "0.0.0.0")
port=3000, # Server port (default: 3000)
# Authentication
basic_auth=("user", "pass"), # Override env var credentials
# Behavior
auto_answer=True, # Answer calls automatically
use_pom=True, # Use Prompt Object Model
# Recording
record_call=False, # Enable call recording
record_format="mp4", # Recording format
record_stereo=True, # Stereo recording
# Tokens and Security
token_expiry_secs=3600, # Function token expiration
# Advanced
default_webhook_url=None, # Override webhook URL
agent_id=None, # Custom agent ID (auto-generated)
native_functions=None, # Built-in SignalWire functions
schema_path=None, # Custom SWML schema path
suppress_logs=False, # Disable logging
config_file=None # Load from config file
)
Parameter Reference
| Parameter | Type | Default | Description |
|---|---|---|---|
name | str | Required | Unique identifier for the agent |
route | str | "/" | HTTP route where agent is accessible |
host | str | "0.0.0.0" | IP address to bind server |
port | int | 3000 | Port number for server |
basic_auth | tuple | None | (username, password) for auth |
use_pom | bool | True | Enable Prompt Object Model |
auto_answer | bool | True | Auto-answer incoming calls |
record_call | bool | False | Enable call recording |
record_format | str | "mp4" | Recording file format |
record_stereo | bool | True | Record in stereo |
token_expiry_secs | int | 3600 | Token validity period |
native_functions | list | None | SignalWire native functions |
suppress_logs | bool | False | Disable agent logs |
Creating an Agent
Method 1: Class-Based (Recommended)
from signalwire_agents import AgentBase, SwaigFunctionResult
class MyAgent(AgentBase):
def __init__(self):
super().__init__(name="my-agent")
self._setup()
def _setup(self):
# Voice
self.add_language("English", "en-US", "rime.spore")
# Prompts
self.prompt_add_section("Role", "You are a helpful assistant.")
# Functions
self.define_tool(
name="greet",
description="Greet the user",
parameters={},
handler=self.greet
)
def greet(self, args, raw_data):
return SwaigFunctionResult("Hello! How can I help you today?")
if __name__ == "__main__":
agent = MyAgent()
agent.run()
Method 2: Instance-Based
from signalwire_agents import AgentBase
agent = AgentBase(name="quick-agent")
agent.add_language("English", "en-US", "rime.spore")
agent.prompt_add_section("Role", "You are a helpful assistant.")
agent.run()
Method 3: Declarative (PROMPT_SECTIONS)
from signalwire_agents import AgentBase
class DeclarativeAgent(AgentBase):
PROMPT_SECTIONS = {
"Role": "You are a helpful customer service agent.",
"Guidelines": [
"Be professional and courteous",
"Ask clarifying questions when needed",
"Keep responses concise"
],
"Rules": {
"body": "Always follow these rules:",
"bullets": [
"Never share customer data",
"Escalate complex issues"
]
}
}
def __init__(self):
super().__init__(name="declarative-agent")
self.add_language("English", "en-US", "rime.spore")
Key Methods
Configuration Methods
# Voice and Language
agent.add_language(name, code, voice) # Add language support
agent.set_languages(languages) # Set all languages at once
# Prompts
agent.prompt_add_section(title, body) # Add prompt section
agent.prompt_add_subsection(parent, title) # Add subsection
agent.set_post_prompt(text) # Set post-call summary prompt
# AI Parameters
agent.set_params(params_dict) # Set AI behavior parameters
agent.set_param_value(key, value) # Set single parameter
# Speech Recognition
agent.add_hints(hints_list) # Add speech hints
agent.add_hint(hint_string) # Add single hint
# Functions
agent.define_tool(name, description, ...) # Define SWAIG function
agent.add_skill(skill_name) # Add a skill
# Pronunciation
agent.add_pronunciation(replace, with_text) # Add pronunciation rule
Runtime Methods
# Start server
agent.run(host="0.0.0.0", port=3000)
# Get SWML document
swml = agent.get_swml()
# Access components
agent.pom # Prompt Object Model
agent.data_map # DataMap builder
Agent Lifecycle
┌─────────────────────────────────────────────────────────────────────────────┐
│ Agent Lifecycle │
├─────────────────────────────────────────────────────────────────────────────┤
│ │
│ 1. Instantiation │
│ └── __init__() called │
│ ├── Mixins initialized │
│ ├── Config loaded │
│ └── Routes registered │
│ │
│ 2. Configuration │
│ └── Setup methods called │
│ ├── add_language() │
│ ├── prompt_add_section() │
│ ├── define_tool() │
│ └── add_skill() │
│ │
│ 3. Server Start │
│ └── run() called │
│ ├── FastAPI app created │
│ ├── Routes mounted │
│ └── Uvicorn started │
│ │
│ 4. Request Handling │
│ ├── GET / ──► Return SWML document │
│ ├── POST / ──► Return SWML document │
│ └── POST /swaig ──► Execute SWAIG function │
│ │
└─────────────────────────────────────────────────────────────────────────────┘
Configuration File
Load configuration from a YAML/JSON file:
agent = AgentBase(
name="my-agent",
config_file="config/agent.yaml"
)
# config/agent.yaml
name: my-agent
route: /support
host: 0.0.0.0
port: 3000
Environment Variables
AgentBase respects these environment variables:
| Variable | Purpose |
|---|---|
SWML_BASIC_AUTH_USER | Basic auth username |
SWML_BASIC_AUTH_PASSWORD | Basic auth password |
SWML_PROXY_URL_BASE | Base URL for webhooks behind proxy |
SWML_SSL_ENABLED | Enable SSL |
SWML_SSL_CERT_PATH | SSL certificate path |
SWML_SSL_KEY_PATH | SSL key path |
SWML_DOMAIN | Domain for SSL |
Multi-Agent Server
Run multiple agents on one server:
from signalwire_agents import AgentServer
class SupportAgent(AgentBase):
def __init__(self):
super().__init__(name="support", route="/support")
# ... configuration
class SalesAgent(AgentBase):
def __init__(self):
super().__init__(name="sales", route="/sales")
# ... configuration
# Register multiple agents
server = AgentServer()
server.register(SupportAgent())
server.register(SalesAgent())
server.run(host="0.0.0.0", port=3000)
Access agents at:
http://localhost:3000/supporthttp://localhost:3000/sales
Best Practices
- Use class-based agents for anything beyond simple prototypes
- Organize configuration into logical private methods
- Set explicit credentials in production via environment variables
- Use meaningful agent names for logging and debugging
- Test with swaig-test before deploying
class WellOrganizedAgent(AgentBase):
def __init__(self):
super().__init__(name="organized-agent")
self._configure_voice()
self._configure_prompts()
self._configure_functions()
self._configure_skills()
def _configure_voice(self):
self.add_language("English", "en-US", "rime.spore")
self.set_params({
"end_of_speech_timeout": 500,
"attention_timeout": 15000
})
def _configure_prompts(self):
self.prompt_add_section("Role", "You are a helpful assistant.")
def _configure_functions(self):
self.define_tool(
name="help",
description="Get help",
parameters={},
handler=self.get_help
)
def _configure_skills(self):
self.add_skill("datetime")
def get_help(self, args, raw_data):
return SwaigFunctionResult("I can help you with...")
