MCP Gateway

Summary: The MCP Gateway bridges Model Context Protocol (MCP) servers with SignalWire AI agents, enabling your agents to use any MCP-compatible tool through a managed gateway service.

What is MCP?

The Model Context Protocol (MCP) is an open standard for connecting AI systems to external tools and data sources. MCP servers expose "tools" (functions) that AI models can call—similar to SWAIG functions but using a standardized protocol.

The MCP Gateway acts as a bridge: it runs MCP servers and exposes their tools as SWAIG functions that SignalWire agents can call. This lets you leverage the growing ecosystem of MCP tools without modifying your agent code.

Architecture Overview

When to Use MCP Gateway

Good use cases:

Integrating existing MCP tools without modification
Using community MCP servers (database connectors, APIs, etc.)
Isolating tool execution in sandboxed processes
Managing multiple tool services from one gateway
Session-based tools that maintain state across calls

Consider alternatives when:

You need simple, stateless functions (use SWAIG directly)
You're building custom tools from scratch (SWAIG is simpler)
Low latency is critical (gateway adds network hop)
You don't need MCP ecosystem compatibility

Components

The MCP Gateway consists of:

Component	Purpose
Gateway Service	HTTP server that manages MCP servers and sessions
MCP Manager	Spawns and communicates with MCP server processes
Session Manager	Tracks per-call sessions with automatic cleanup
mcp_gateway Skill	SignalWire skill that connects agents to the gateway

Installation

The MCP Gateway is included in the SignalWire Agents SDK. Install with the gateway dependencies:

pip install "signalwire-agents[mcp-gateway]"

Once installed, the mcp-gateway CLI command is available:

mcp-gateway --help

Setting Up the Gateway

1. Configuration

Create a configuration file for the gateway:

{
    "server": {
        "host": "0.0.0.0",
        "port": 8080,
        "auth_user": "admin",
        "auth_password": "your-secure-password"
    },
    "services": {
        "todo": {
            "command": ["python3", "./todo_mcp.py"],
            "description": "Todo list management",
            "enabled": true,
            "sandbox": {
                "enabled": true,
                "resource_limits": true
            }
        },
        "calculator": {
            "command": ["node", "./calc_mcp.js"],
            "description": "Mathematical calculations",
            "enabled": true
        }
    },
    "session": {
        "default_timeout": 300,
        "max_sessions_per_service": 100,
        "cleanup_interval": 60
    }
}

Configuration supports environment variable substitution:

{
    "server": {
        "auth_password": "${MCP_AUTH_PASSWORD|changeme}"
    }
}

2. Start the Gateway

# Using the installed CLI command
mcp-gateway -c config.json

# Or with Docker (in the mcp_gateway directory)
cd mcp_gateway
./mcp-docker.sh start

The gateway starts on the configured port (default 8080).

3. Connect Your Agent

from signalwire_agents import AgentBase

class MCPAgent(AgentBase):
    def __init__(self):
        super().__init__(name="mcp-agent")
        self.add_language("English", "en-US", "rime.spore")

        # Connect to MCP Gateway
        self.add_skill("mcp_gateway", {
            "gateway_url": "http://localhost:8080",
            "auth_user": "admin",
            "auth_password": "your-secure-password",
            "services": [
                {"name": "todo", "tools": "*"},      # All tools
                {"name": "calculator", "tools": ["add", "multiply"]}  # Specific tools
            ]
        })

        self.prompt_add_section(
            "Role",
            "You are an assistant with access to a todo list and calculator."
        )

if __name__ == "__main__":
    agent = MCPAgent()
    agent.run()

Skill Configuration

The mcp_gateway skill accepts these parameters:

Parameter	Type	Description	Default
`gateway_url`	string	Gateway service URL	Required
`auth_user`	string	Basic auth username	None
`auth_password`	string	Basic auth password	None
`auth_token`	string	Bearer token (alternative to basic auth)	None
`services`	array	Services and tools to enable	All services
`session_timeout`	integer	Session timeout in seconds	300
`tool_prefix`	string	Prefix for SWAIG function names	"mcp_"
`retry_attempts`	integer	Connection retry attempts	3
`request_timeout`	integer	Request timeout in seconds	30
`verify_ssl`	boolean	Verify SSL certificates	true

Service Configuration

Each service in the services array specifies:

{
    "name": "service_name",    # Service name from gateway config
    "tools": "*"               # All tools, or list: ["tool1", "tool2"]
}

Tools are exposed as SWAIG functions with names like mcp_{service}_{tool}.

Gateway API

The gateway exposes these REST endpoints:

Endpoint	Method	Purpose
`/health`	GET	Health check (no auth)
`/services`	GET	List available services
`/services/{name}/tools`	GET	List tools for a service
`/services/{name}/call`	POST	Call a tool
`/sessions`	GET	List active sessions
`/sessions/{id}`	DELETE	Close a session

Example API Calls

# List services
curl -u admin:password http://localhost:8080/services

# Get tools for a service
curl -u admin:password http://localhost:8080/services/todo/tools

# Call a tool
curl -u admin:password -X POST http://localhost:8080/services/todo/call \
  -H "Content-Type: application/json" \
  -d '{
    "tool": "add_todo",
    "arguments": {"text": "Buy groceries"},
    "session_id": "call-123",
    "timeout": 300
  }'

Session Management

Sessions are tied to SignalWire call IDs:

First tool call: Gateway creates new MCP process and session
Subsequent calls: Same session reused (process stays alive)
Call ends: Hangup hook closes session and terminates process

This enables stateful tools—a todo list MCP can maintain items across multiple tool calls within the same phone call.

# Session persists across multiple tool calls in same call
# Call 1: "Add milk to my list" → mcp_todo_add_todo(text="milk")
# Call 2: "What's on my list?"  → mcp_todo_list_todos() → Returns "milk"
# Call 3: "Add eggs"            → mcp_todo_add_todo(text="eggs")
# Call 4: "Read my list"        → mcp_todo_list_todos() → Returns "milk, eggs"

Security Features

Authentication

The gateway supports two authentication methods:

{
    "server": {
        "auth_user": "admin",
        "auth_password": "secure-password",
        "auth_token": "optional-bearer-token"
    }
}

Sandbox Isolation

MCP processes run in sandboxed environments:

{
    "services": {
        "untrusted_tool": {
            "command": ["python3", "tool.py"],
            "sandbox": {
                "enabled": true,
                "resource_limits": true,
                "restricted_env": true
            }
        }
    }
}

Sandbox levels:

Level	Settings	Use Case
High	`enabled: true, resource_limits: true, restricted_env: true`	Untrusted tools
Medium	`enabled: true, resource_limits: true, restricted_env: false`	Tools needing env vars
None	`enabled: false`	Trusted internal tools

Resource limits (when enabled):

CPU: 300 seconds
Memory: 512 MB
Processes: 10
File size: 10 MB

Rate Limiting

Configure rate limits per endpoint:

{
    "rate_limiting": {
        "default_limits": ["200 per day", "50 per hour"],
        "tools_limit": "30 per minute",
        "call_limit": "10 per minute"
    }
}

Writing MCP Servers

MCP servers communicate via JSON-RPC 2.0 over stdin/stdout. The gateway spawns these as child processes and communicates with them via stdin/stdout. Here's a minimal example:

#!/usr/bin/env python3
# greeter_mcp.py - Simple MCP server that the gateway can spawn
"""Simple MCP server example"""
import json
import sys

def handle_request(request):
    method = request.get("method")
    req_id = request.get("id")

    if method == "initialize":
        return {
            "jsonrpc": "2.0",
            "id": req_id,
            "result": {
                "protocolVersion": "2024-11-05",
                "serverInfo": {"name": "example", "version": "1.0.0"},
                "capabilities": {"tools": {}}
            }
        }

    elif method == "tools/list":
        return {
            "jsonrpc": "2.0",
            "id": req_id,
            "result": {
                "tools": [
                    {
                        "name": "greet",
                        "description": "Greet someone by name",
                        "inputSchema": {
                            "type": "object",
                            "properties": {
                                "name": {"type": "string", "description": "Name to greet"}
                            },
                            "required": ["name"]
                        }
                    }
                ]
            }
        }

    elif method == "tools/call":
        tool_name = request["params"]["name"]
        args = request["params"].get("arguments", {})

        if tool_name == "greet":
            name = args.get("name", "World")
            return {
                "jsonrpc": "2.0",
                "id": req_id,
                "result": {
                    "content": [{"type": "text", "text": f"Hello, {name}!"}]
                }
            }

    return {"jsonrpc": "2.0", "id": req_id, "error": {"code": -32601, "message": "Method not found"}}

def main():
    for line in sys.stdin:
        request = json.loads(line)
        response = handle_request(request)
        print(json.dumps(response), flush=True)

if __name__ == "__main__":
    main()

Testing

Test with swaig-test

# List available tools (including MCP tools)
swaig-test greeter_agent.py --list-tools

# Execute the greet tool
swaig-test greeter_agent.py --call-id test-session --exec mcp_greeter_greet --name "World"

# Generate SWML
swaig-test greeter_agent.py --dump-swml

Test Gateway Directly

# Health check (no auth required)
curl http://localhost:8080/health

# List services
curl -u admin:secure-password http://localhost:8080/services

# Get tools for the greeter service
curl -u admin:secure-password http://localhost:8080/services/greeter/tools

# Call the greet tool
curl -u admin:secure-password -X POST http://localhost:8080/services/greeter/call \
  -H "Content-Type: application/json" \
  -d '{"tool": "greet", "session_id": "test", "arguments": {"name": "World"}}'

# List active sessions
curl -u admin:secure-password http://localhost:8080/sessions

Docker Deployment

The gateway includes Docker support:

cd mcp_gateway

# Build and start
./mcp-docker.sh build
./mcp-docker.sh start

# Or use docker-compose
docker-compose up -d

# View logs
./mcp-docker.sh logs -f

# Stop
./mcp-docker.sh stop

Complete Example

#!/usr/bin/env python3
# greeter_agent.py - Agent with MCP Gateway integration
"""Agent with MCP Gateway integration using the greeter MCP server"""
from signalwire_agents import AgentBase

class GreeterAgent(AgentBase):
    def __init__(self):
        super().__init__(name="greeter-agent")
        self.add_language("English", "en-US", "rime.spore")

        # Connect to MCP Gateway
        self.add_skill("mcp_gateway", {
            "gateway_url": "http://localhost:8080",
            "auth_user": "admin",
            "auth_password": "secure-password",
            "services": [
                {"name": "greeter", "tools": "*"}
            ]
        })

        self.prompt_add_section(
            "Role",
            "You are a friendly assistant that can greet people by name."
        )

        self.prompt_add_section(
            "Guidelines",
            bullets=[
                "When users want to greet someone, use the mcp_greeter_greet function",
                "Always be friendly and helpful",
                "The greet function requires a name parameter"
            ]
        )

if __name__ == "__main__":
    agent = GreeterAgent()
    agent.run()

Troubleshooting

Issue	Solution
"Connection refused"	Verify gateway is running and URL is correct
"401 Unauthorized"	Check auth credentials match gateway config
"Service not found"	Verify service name and that it's enabled
"Tool not found"	Check tool exists with `/services/{name}/tools`
"Session timeout"	Increase `session_timeout` or `default_timeout`
Tools not appearing	Verify `services` config includes the service

Topic	Reference
Built-in Skills	Built-in Skills
SWAIG Functions	Defining Functions
Testing	swaig-test CLI

Additional resources

MCP Gateway

MCP Gateway

What is MCP?

Architecture Overview

When to Use MCP Gateway

Components

Installation

Setting Up the Gateway

1. Configuration

2. Start the Gateway

3. Connect Your Agent

Skill Configuration

Service Configuration

Gateway API

Example API Calls

Session Management

Security Features

Authentication

Sandbox Isolation

Rate Limiting

Writing MCP Servers

Testing

Test with swaig-test

Test Gateway Directly

Docker Deployment

Complete Example

Troubleshooting

See Also

MCP Gateway​

What is MCP?​

Architecture Overview​

When to Use MCP Gateway​

Components​

Installation​

Setting Up the Gateway​

1. Configuration​

2. Start the Gateway​

3. Connect Your Agent​

Skill Configuration​

Service Configuration​

Gateway API​

Example API Calls​

Session Management​

Security Features​

Authentication​

Sandbox Isolation​

Rate Limiting​

Writing MCP Servers​

Testing​

Test with swaig-test​

Test Gateway Directly​

Docker Deployment​

Complete Example​

Troubleshooting​

See Also​

MCP Gateway

What is MCP?

Architecture Overview

When to Use MCP Gateway

Components

Installation

Setting Up the Gateway

1. Configuration

2. Start the Gateway

3. Connect Your Agent

Skill Configuration

Service Configuration

Gateway API

Example API Calls

Session Management

Security Features

Authentication

Sandbox Isolation

Rate Limiting

Writing MCP Servers

Testing

Test with swaig-test

Test Gateway Directly

Docker Deployment

Complete Example

Troubleshooting

See Also
