Call Transfer

Summary: Transfer calls to other destinations using connect() for phone numbers/SIP and swml_transfer() for SWML endpoints. Support for both permanent and temporary transfers.

Call transfer is essential for agents that need to escalate to humans, route to specialized departments, or hand off to other AI agents. The SDK provides multiple transfer mechanisms, each suited to different scenarios.

Understanding the difference between these methods—and when to use each—helps you build agents that route calls efficiently while maintaining a good caller experience.

Choosing a Transfer Method

The SDK offers several ways to transfer calls. Here's how to choose:

Method	Best For	Destination	What Happens
`connect()`	Phone numbers, SIP	PSTN, SIP endpoints	Direct telephony connection
`swml_transfer()`	Other AI agents	SWML URLs	Hand off to another agent
`sip_refer()`	SIP environments	SIP URIs	SIP REFER signaling

Use connect() when:

Transferring to a phone number (human agents, call centers)
Connecting to SIP endpoints on your PBX
You need caller ID control on the outbound leg

Use swml_transfer() when:

Handing off to another AI agent
The destination is a SWML endpoint
You want the call to continue with different agent logic

Use sip_refer() when:

Your infrastructure uses SIP REFER for transfers
Integrating with traditional telephony systems that expect REFER

Transfer Types

Permanent Transfer (`final=True`)

Call exits the agent completely
Caller connected directly to destination
Agent conversation ends
Use for: Handoff to human, transfer to another system

Temporary Transfer (`final=False`)

Call returns to agent when far end hangs up
Agent can continue conversation after transfer
Use for: Conferencing, brief consultations

Basic Phone Transfer

from signalwire_agents import AgentBase
from signalwire_agents.core.function_result import SwaigFunctionResult


class TransferAgent(AgentBase):
    def __init__(self):
        super().__init__(name="transfer-agent")
        self.add_language("English", "en-US", "rime.spore")

        self.prompt_add_section(
            "Role",
            "You are a receptionist who can transfer calls to different departments."
        )

        self.define_tool(
            name="transfer_to_sales",
            description="Transfer the caller to the sales department",
            parameters={"type": "object", "properties": {}},
            handler=self.transfer_to_sales
        )

    def transfer_to_sales(self, args, raw_data):
        return (
            SwaigFunctionResult("Transferring you to sales now.")
            .connect("+15551234567", final=True)
        )


if __name__ == "__main__":
    agent = TransferAgent()
    agent.run()

Connect Method Parameters

Parameter	Type	Default	Description
`destination`	str	required	Phone number, SIP address, or URI
`final`	bool	True	Permanent (True) or temporary (False)
`from_addr`	str	None	Override caller ID for outbound leg

Permanent vs Temporary Transfer

from signalwire_agents import AgentBase
from signalwire_agents.core.function_result import SwaigFunctionResult


class SmartTransferAgent(AgentBase):
    def __init__(self):
        super().__init__(name="smart-transfer-agent")
        self.add_language("English", "en-US", "rime.spore")

        self.prompt_add_section(
            "Role",
            "You can transfer calls permanently or temporarily."
        )

        self._register_functions()

    def _register_functions(self):
        self.define_tool(
            name="transfer_permanent",
            description="Permanently transfer to support (call ends with agent)",
            parameters={
                "type": "object",
                "properties": {
                    "number": {"type": "string", "description": "Phone number"}
                },
                "required": ["number"]
            },
            handler=self.transfer_permanent
        )

        self.define_tool(
            name="transfer_temporary",
            description="Temporarily connect to expert, then return to agent",
            parameters={
                "type": "object",
                "properties": {
                    "number": {"type": "string", "description": "Phone number"}
                },
                "required": ["number"]
            },
            handler=self.transfer_temporary
        )

    def transfer_permanent(self, args, raw_data):
        number = args.get("number")
        return (
            SwaigFunctionResult(f"Transferring you now. Goodbye!")
            .connect(number, final=True)
        )

    def transfer_temporary(self, args, raw_data):
        number = args.get("number")
        return (
            SwaigFunctionResult("Connecting you briefly. I'll be here when you're done.")
            .connect(number, final=False)
        )


if __name__ == "__main__":
    agent = SmartTransferAgent()
    agent.run()

SIP Transfer

Transfer to SIP endpoints:

def transfer_to_sip(self, args, raw_data):
    return (
        SwaigFunctionResult("Connecting to internal support")
        .connect("sip:support@company.com", final=True)
    )

Transfer with Caller ID Override

def transfer_with_custom_callerid(self, args, raw_data):
    return (
        SwaigFunctionResult("Connecting you now")
        .connect(
            "+15551234567",
            final=True,
            from_addr="+15559876543"  # Custom caller ID
        )
    )

SWML Transfer

Transfer to another SWML endpoint (another agent):

from signalwire_agents import AgentBase
from signalwire_agents.core.function_result import SwaigFunctionResult


class MultiAgentTransfer(AgentBase):
    def __init__(self):
        super().__init__(name="multi-agent-transfer")
        self.add_language("English", "en-US", "rime.spore")

        self.prompt_add_section("Role", "You route calls to specialized agents.")

        self.define_tool(
            name="transfer_to_billing",
            description="Transfer to the billing specialist agent",
            parameters={"type": "object", "properties": {}},
            handler=self.transfer_to_billing
        )

    def transfer_to_billing(self, args, raw_data):
        return (
            SwaigFunctionResult(
                "I'm transferring you to our billing specialist.",
                post_process=True  # Speak message before transfer
            )
            .swml_transfer(
                dest="https://agents.example.com/billing",
                ai_response="How else can I help?",  # Used if final=False
                final=True
            )
        )


if __name__ == "__main__":
    agent = MultiAgentTransfer()
    agent.run()

Transfer Flow

┌─────────────────────────────────────────────────────────────────────────────┐
│                    Transfer Flow Diagram                                    │
├─────────────────────────────────────────────────────────────────────────────┤
│                                                                             │
│  Permanent Transfer (final=True):                                           │
│                                                                             │
│  Caller ──→ Agent ──→ "Transferring..." ──→ Destination                     │
│                                │                    │                       │
│                                └── Agent exits ─────┘                       │
│                                                                             │
│  Temporary Transfer (final=False):                                          │
│                                                                             │
│  Caller ──→ Agent ──→ "Connecting..." ──→ Destination                       │
│                │                               │                            │
│                │                               ▼                            │
│                │                        Destination hangs up                │
│                │                               │                            │
│                └───────────── Returns ─────────┘                            │
│                                    │                                        │
│                                    ▼                                        │
│                          Agent continues conversation                       │
│                                                                             │
└─────────────────────────────────────────────────────────────────────────────┘

Department Transfer Example

from signalwire_agents import AgentBase
from signalwire_agents.core.function_result import SwaigFunctionResult


class ReceptionistAgent(AgentBase):
    """Receptionist that routes calls to departments"""

    DEPARTMENTS = {
        "sales": "+15551111111",
        "support": "+15552222222",
        "billing": "+15553333333",
        "hr": "+15554444444"
    }

    def __init__(self):
        super().__init__(name="receptionist-agent")
        self.add_language("English", "en-US", "rime.spore")

        self.prompt_add_section(
            "Role",
            "You are the company receptionist. Help callers reach the right department."
        )

        self.prompt_add_section(
            "Available Departments",
            "Sales, Support, Billing, Human Resources (HR)"
        )

        self.define_tool(
            name="transfer_to_department",
            description="Transfer caller to a specific department",
            parameters={
                "type": "object",
                "properties": {
                    "department": {
                        "type": "string",
                        "description": "Department name",
                        "enum": ["sales", "support", "billing", "hr"]
                    }
                },
                "required": ["department"]
            },
            handler=self.transfer_to_department
        )

    def transfer_to_department(self, args, raw_data):
        dept = args.get("department", "").lower()

        if dept not in self.DEPARTMENTS:
            return SwaigFunctionResult(
                f"I don't recognize the department '{dept}'. "
                "Available departments are: Sales, Support, Billing, and HR."
            )

        number = self.DEPARTMENTS[dept]
        dept_name = dept.upper() if dept == "hr" else dept.capitalize()

        return (
            SwaigFunctionResult(f"Transferring you to {dept_name} now. Have a great day!")
            .connect(number, final=True)
        )


if __name__ == "__main__":
    agent = ReceptionistAgent()
    agent.run()

Sending SMS During Transfer

Notify the user via SMS before transfer:

def transfer_with_sms(self, args, raw_data):
    caller_number = raw_data.get("caller_id_number")

    return (
        SwaigFunctionResult("I'm transferring you and sending a confirmation text.")
        .send_sms(
            to_number=caller_number,
            from_number="+15559876543",
            body="You're being transferred to our support team. Reference #12345"
        )
        .connect("+15551234567", final=True)
    )

Post-Process Transfer

Use post_process=True to have the AI speak before executing the transfer:

def announced_transfer(self, args, raw_data):
    return (
        SwaigFunctionResult(
            "Please hold while I transfer you to our specialist. "
            "This should only take a moment.",
            post_process=True  # AI speaks this before transfer executes
        )
        .connect("+15551234567", final=True)
    )

Warm vs Cold Transfers

Understanding the difference between warm and cold transfers helps you design better caller experiences.

The caller is connected to the destination without any preparation. The destination answers not knowing who's calling or why.

def cold_transfer(self, args, raw_data):
    return (
        SwaigFunctionResult("Transferring you to support now.")
        .connect("+15551234567", final=True)
    )

When to use cold transfers:

High-volume call centers where speed matters
After-hours routing to voicemail
Simple department routing where context isn't needed
When the destination has caller ID and can look up the caller

Warm Transfer (Announced Transfer)

The agent announces the transfer and potentially provides context before connecting. In traditional telephony, this means speaking to the destination first. With AI agents, this typically means:

Informing the caller about the transfer
Optionally sending context to the destination
Then executing the transfer

def warm_transfer_with_context(self, args, raw_data):
    caller_number = raw_data.get("caller_id_number")
    call_summary = "Caller needs help with billing dispute"

    return (
        SwaigFunctionResult(
            "I'm transferring you to our billing specialist. "
            "I'll let them know about your situation.",
            post_process=True
        )
        # Send context via SMS to the agent's phone
        .send_sms(
            to_number="+15551234567",
            from_number="+15559876543",
            body=f"Incoming transfer: {caller_number}\n{call_summary}"
        )
        .connect("+15551234567", final=True)
    )

When to use warm transfers:

Escalations where context improves resolution
VIP callers who expect personalized service
Complex issues that need explanation
When you want to improve first-call resolution

Handling Transfer Failures

Transfers can fail for various reasons: busy lines, no answer, invalid numbers. Plan for these scenarios.

Validating Before Transfer

Check that the destination is valid before attempting:

def transfer_to_department(self, args, raw_data):
    dept = args.get("department", "").lower()

    DEPARTMENTS = {
        "sales": "+15551111111",
        "support": "+15552222222",
    }

    if dept not in DEPARTMENTS:
        return SwaigFunctionResult(
            f"I don't have a number for '{dept}'. "
            "I can transfer you to Sales or Support."
        )

    return (
        SwaigFunctionResult(f"Transferring to {dept}.")
        .connect(DEPARTMENTS[dept], final=True)
    )

Fallback Strategies

For temporary transfers (final=False), you can handle what happens when the transfer fails or the far end hangs up:

def consultation_transfer(self, args, raw_data):
    return (
        SwaigFunctionResult(
            "Let me connect you with a specialist briefly."
        )
        .connect(
            "+15551234567",
            final=False  # Call returns to agent if transfer fails or ends
        )
    )
    # When the call returns, the agent continues the conversation
    # The ai_response parameter in swml_transfer can specify what to say

Transfer Patterns

Escalation to Human

The most common pattern—escalate to a human when the AI can't help:

def escalate_to_human(self, args, raw_data):
    reason = args.get("reason", "Customer requested")

    # Log the escalation
    self.log.info(f"Escalating call: {reason}")

    return (
        SwaigFunctionResult(
            "I understand you'd like to speak with a person. "
            "Let me transfer you to one of our team members.",
            post_process=True
        )
        .connect("+15551234567", final=True)
    )

Queue-Based Routing

Route to different queues based on caller needs:

def route_to_queue(self, args, raw_data):
    issue_type = args.get("issue_type", "general")

    QUEUES = {
        "billing": "+15551111111",
        "technical": "+15552222222",
        "sales": "+15553333333",
        "general": "+15554444444"
    }

    queue_number = QUEUES.get(issue_type, QUEUES["general"])

    return (
        SwaigFunctionResult(f"Routing you to our {issue_type} team.")
        .connect(queue_number, final=True)
    )

Agent-to-Agent Handoff

Transfer between AI agents with different specializations:

def handoff_to_specialist(self, args, raw_data):
    specialty = args.get("specialty")

    SPECIALIST_AGENTS = {
        "billing": "https://agents.example.com/billing",
        "technical": "https://agents.example.com/technical",
        "sales": "https://agents.example.com/sales"
    }

    if specialty not in SPECIALIST_AGENTS:
        return SwaigFunctionResult(
            "I don't have a specialist for that area. Let me help you directly."
        )

    return (
        SwaigFunctionResult(
            f"I'm connecting you with our {specialty} specialist.",
            post_process=True
        )
        .swml_transfer(
            dest=SPECIALIST_AGENTS[specialty],
            final=True
        )
    )

Transfer Methods Summary

Method	Use Case	Destination Types
`connect()`	Direct call transfer	Phone numbers, SIP URIs
`swml_transfer()`	Transfer to another agent	SWML endpoint URLs
`sip_refer()`	SIP-based transfer	SIP URIs

Best Practices

DO:

Use post_process=True to announce transfers
Validate destination numbers before transfer
Log transfers for tracking and compliance
Use final=False for consultation/return flows
Provide clear confirmation to the caller
Send context to the destination when helpful
Have fallback options if transfer fails

DON'T:

Transfer without informing the caller
Use hard-coded numbers without validation
Forget to handle transfer failures gracefully
Use final=True when you need the call to return
Transfer to unverified or potentially invalid destinations

Additional resources

Call Transfer

Call Transfer

Choosing a Transfer Method

Transfer Types

Permanent Transfer (`final=True`)

Temporary Transfer (`final=False`)

Basic Phone Transfer

Connect Method Parameters

Permanent vs Temporary Transfer

SIP Transfer

Transfer with Caller ID Override

SWML Transfer

Transfer Flow

Department Transfer Example

Sending SMS During Transfer

Post-Process Transfer

Warm vs Cold Transfers

Cold Transfer (Blind Transfer)

Warm Transfer (Announced Transfer)

Handling Transfer Failures

Validating Before Transfer

Fallback Strategies

Transfer Patterns

Escalation to Human

Queue-Based Routing

Agent-to-Agent Handoff

Transfer Methods Summary

Best Practices

Call Transfer​

Choosing a Transfer Method​

Transfer Types​

Permanent Transfer (final=True)​

Temporary Transfer (final=False)​

Basic Phone Transfer​

Connect Method Parameters​

Permanent vs Temporary Transfer​

SIP Transfer​

Transfer with Caller ID Override​

SWML Transfer​

Transfer Flow​

Department Transfer Example​

Sending SMS During Transfer​

Post-Process Transfer​

Warm vs Cold Transfers​

Cold Transfer (Blind Transfer)​

Warm Transfer (Announced Transfer)​

Handling Transfer Failures​

Validating Before Transfer​

Fallback Strategies​

Transfer Patterns​

Escalation to Human​

Queue-Based Routing​

Agent-to-Agent Handoff​

Transfer Methods Summary​

Best Practices​

Call Transfer

Choosing a Transfer Method

Transfer Types

Permanent Transfer (`final=True`)

Temporary Transfer (`final=False`)

Basic Phone Transfer

Connect Method Parameters

Permanent vs Temporary Transfer

SIP Transfer

Transfer with Caller ID Override

SWML Transfer

Transfer Flow

Department Transfer Example

Sending SMS During Transfer

Post-Process Transfer

Warm vs Cold Transfers

Cold Transfer (Blind Transfer)

Warm Transfer (Announced Transfer)

Handling Transfer Failures

Validating Before Transfer

Fallback Strategies

Transfer Patterns

Escalation to Human

Queue-Based Routing

Agent-to-Agent Handoff

Transfer Methods Summary

Best Practices
